Engineered with a robust structure, built to last, the Highlight Merchandiser® freezer case significantly reduces energy usage when compared to similar cases. The CoolView® Envision® doors are designed to resist condensation and sweating, even in humid store conditions. Choose a Highlight Merchandiser® tall case to add an extra 5” of vertical merchandising space. The sturdy 24” deep shelves provide greater product capacity and maximize the impact of the display.
Key Features of the Highlight Merchandiser Freezers
To be a Highlight means to be the focus, and your products will be just that with the Highlight Merchandiser®. The state-of-the-art design makes for easy merchandising and showcases your products beautifully, making them irresistible to shoppers!
ChillBrite® LED Lighting
LED lights provide even, energy-saving product illumination creating a beautiful display that won’t fade products.
Shelving
2 or 4 positioned (0, 5, 10, or 15 degree) adjustable shelving.
Reduced Energy Consumption ~ Lower Operating Costs
Our refrigeration technology ensures efficient cooling, saving you money on energy bills while providing reliable and sustainable freezing solutions for your needs.
Easy Cleaning
The removable back panels allow for effortless and speedy cleaning. Easily removable bottom coil covers with integral air return can be removed without tools, ensuring a hassle-free and convenient cleaning process.
Easy Installation by Forklift
Engineered for easy forklift handling, this design allows lifting from either end. The reinforced bottom assembly featuring steel forklift plates not only saves time during unloading but also streamlines the installation process.
Rigorous Testing
Rigorous testing is conducted to guarantee consistent and even temperatures throughout the case, ensuring a uniform and reliable temperature performance.
SSC fan motors
Deliver exceptional airflow with a reduced operational cost while ensuring proven reliability.
Surface-Mounted Doors
Engineered for optimal energy efficiency and user-friendly maintenance.
2 1/2″ Foam Panels
Keep the cold inside with the thickest insulation in the industry.
Easy Maintenance Access
An electrical encloser located behind the kick plate provides quick and easy access for maintenance.
CoolView® Envision® doors
Energy-efficient and lab-tested for optimal performance and protection from condensation. Choose 68" or 73" (case height dependent) for maximum product visibility.
Structural End Frame
The structural end frame of these cases is built for long-term durability, designed to endure well into the future. They are exceptionally strong, with the ability to support up to 300 lbs. on top of the case, even allowing you to stand on it while working.
Hybrid™ Option
The Highlight Merchandiser® freezer is available as a Hybrid™ display case, featuring a field-installed condensing unit kit.
Comprehensive Product Support
We employ a multi-layered approach to support our products from conception to operation. Our local sales representatives can engage with retailers in-person, offering personalized product presentations and Zero Zone solutions. Additionally, our experienced sales and service team collaborates on after-sales support, bringing their expertise in refrigeration to the table.
Standard & Optional Table
Enhance your experience with a range of optional features tailored to your unique needs.
Feature |
Standard |
Optional |
|---|---|---|
Exterior Color |
Black |
Over 36 custom color options |
Interior Color |
Black |
White, Brushed Stainless Steel, Black or White E-Coat, Galvanized |
Door Type |
CoolView® Envision® Black Heated Glass |
CoolView® Envision® Satin Silver Heated Glass,
CoolView® Envision® Polished Silver Heated Glass |
Interior Lighting |
ChillBrite® 4,000K |
ChillBrite® 3,500K |
Shelving |
24" Solid Black or White 2 Position |
22" Solid, Black or White, 2 or 4 Position |
Bottom Wire Rack |
24 3/4" Reversible w/ 4" Front (Black) |
24 3/4" Reversible w/ 4" Front (White), Aluminum Reversible, Black Anodized |
Kickplate |
Flat (Black) |
Louvered (Black), Stainless Steel, Louvered Stainless Steel |
Refrigeration Connection |
ROTB (Refrigeration Out Top Back) |
Inside Case Bottom, Hot Gas (ICB), ROTR (Refrigeration Out Top Right), ROB (Refrigeration Out Back - Hybrid), Pre-Piping |
Electrical Connection |
EOBR (Electric Out Bottom Right) |
EOB (Electric Out Back),
EOT (Electric Out Top) |
Electrical Service |
115/209V -1PH - 60Hz |
208V - 3PH - 60Hz, 115V - 1PH - 60Hz |
Expansion Valve |
Mechanical |
Electronic |
Defrost Type |
Electric (Single Phase) |
Electric (3-Phase), Hot Gas |
Refrigerant |
HFC |
CO2 (45-bar and 90-bar) |
Model
Structure & Sizing Options
Back-to-Back
By installing a single panel between the cases, you can effectively expand the store's depth by an additional 5 1/2 inches. This allows you to merge medium and low-temperature refrigeration units to form a continuous, space-efficient back-to-back arrangement.
Ice Merchandiser
The Robust Rack liner enhances the durability of the ice merchandiser's interior, safeguarding your investment.
Tall and Tall Back-to-Back
If your specific market demands it, we also offer tall back-to-back display cases. These cases are designed to accommodate taller items or products that may require additional vertical space for showcasing.
What refrigerants are supported?
The Highlight Merchandiser Freezer is available with a variety of HFC refrigerants and with CO2 refrigerant for a natural option. Learn more about what refrigerant is right for you here.
What electrical connections are available?
For our Highlight Merchandiser, the standard electrical set up is electric out bottom right but it is also available in with electric out back or top to fit your unique store needs.
Can I customize the color and door options to match my store’s aesthetic?
Yes, absolutely! Our display cases are available in 36 different colors, giving you a wide range of options to perfectly match your store’s aesthetic. Additionally, we offer various door options to further customize the look and functionality of your display cases.
What is the maximum product visibility height?
Based on our 5-door Highlight freezers, they boast an impressive 68.2 ft² of facing, designed to capture customer attention and drive sales with the increased product facings.
Resources
Catalogs & Brochures
Case Studies
Highlight Merchandiser® Display Cases
Hybrid™ Display Cases
Discontinued
Manuals
Highlight Merchandiser® Revit Files
Compare
Highlight Freezer |
Crystal Freezer |
|
| Overview | Our workhorse cooler to meet your varied needs | The modern design and options add functionality to your display |
| Applications | Frozen Food, Ice Cream, Ice Merchandiser | Frozen Food, Ice Cream, Ice Merchandiser |
| Design Style | Classic | Contemporary |
| No of doors | 1,2,3,4,5 | 2,3,4,5 |
| Door Width | 30″ | 30″ |
| Door Height | 68″ | 74″ |
| Facings (5/6 door) | 68.2 ft 2 | 74.4 ft 2 |
| Packout (5/6 door) | 136.4 ft 3 | 146.8 ft 3 |
| Tall Option | Yes (73″ door) | No |
| Back-to-Back | Yes | Yes |
| Back-to-Back Tall | Yes | No |
| Dual Temp | No | Yes |
| Deep | No | No |
| Ice Merchandiser | Yes | Yes |
| High Humidity | Yes | Yes |
Responsible Energy Conservation
Zero Zone dares to present customers with a unique value proposition: quality products that require fewer resources to assemble, use less energy, last longer, and have lessened environmental impact, both during manufacture and in actual use. Our goal is to be the leader in sustainable refrigeration and living up to our name we want to do ZERO harm to the environment and use refrigerants with ZERO ozone depletion. Zero Zone is proud to be a part of the U.S. Environmental Protection Agency’s (EPA) Advanced Refrigeration Partnership for over 15 years. We are also proud Gold Member and supporter of the North American Sustainable Refrigeration Council (NASRC).
